Projects Completed

16

Construction of outfitting Jetty at ABG Shipyard

Jageswar, Dahej (Gujarat)

CLIENT

ABG Shipyard Ltd.

STARTING DATE

15.08.2009

COMPLETION DATE 05.03.2011

SIZE OF JETTY

Main Jetty: 230m. X 27m.

Approach: 49.80m. X 26m.

STRUCTURAL DETAILS

(a) Foundation

1200mm dia. bored pile. 123 Nos.

(b) Substructure

Fender Walls. 20 Nos.

( c) Superstructure Pre-cast & Cast in Situ, main beams & secondary

beams slab of 30cm. thick.

SPECIAL FEATURES Jetty is Constructed in Dahej where daily tidal

variation is more than 8m. High...is highest in

India and 2nd largest in World. Very strong current

of 7.2 knots.
