Background for SCCProfile page 38 595x842

Projects Completed

38 Construction of a bridge across river Passvivali

on Service Road for Ship breaking yard Sosiya -

Alang, Bhavnagar (Gujarat)

CLIENT

Gujarat Maritime Board

STARTING DATE 31.07.1995

COMPLETION DATE 30.10.1996

LENGTH & SPAN OF

248.00m, Span 18 m : 12 nos.

BRIDGE

SIZE OF BRIDGE

225.00m x 8 m

STRUCTURAL DETAILS

(a) Foundation 1200 mm dia bore piles.

Depth of pile : 20.00 m.

(b) Substructure 1.20 m. dia, Two circular R.C.C. piers in

M30 grade concrete with pier cap at

top.

( c) Superstructure Simply supported 4 girder system

beams with deck slab at top

supported on pier cap.

SPECIAL FEATURES This was unique bridge constructed in

river floor and sea tidal attected area.
