Projects Completed

40 Construction of Radial well and approach Bridge

a/c river Sabarmati near Motera Stadium at

Ahmedabad.

CLIENT

Ahmedabad Municipal Corporation

STARTING DATE 09.03.1998

COMPLETION DATE 30.06.2001

SIZE OF BRIDGE 40m. length - 19 Spans.

STRUCTURAL DETAILS

(a) Foundation 80 Nos. of 1200 mm dia. 21m Deep R.C.C.

bored piles.

(b) Substructure Two circular columns with column cap at

top.

( c) Superstructure 40m Long open web fabricated steel

girder.

(d) Carriage Way 4.50 m wide

SPECIAL FEATURES 16 span of super structure are launched

from one end, Radio graphically tested

welding is adopted.
