41 Design and rebuilding of Bridge No. 81, 86, 96 &

96A based on Pile foundation on Bodeli -

Chhotaudaipur NG Railway line

CLIENT Western Railway

STARTING DATE 01.03.1999

COMPLETION DATE 25.07.2000

LENGTH & SPAN OF

The contract involves four Bridges. (a) 4

BRIDGE

span of 9.0m, (b) 9 Span of 18.0m.

STRUCTURAL DETAILS

(a) Foundation 1200mm dia. 16m Deep, 112 Nos. of

RCC liner piles.

(b) Substructure 2 bridges Mass C.C pier & Abutment

with RCC cap. 2 bridges RCC column

with RCC Column cap at top.

( c) Superstructure 2 bridges - solid slab

2 bridges Steel girders

(d)

Single track for NG line

SPECIAL FEATURES The RCC liner bentonite bored piles are

rested on rocky strata.
